Sharp Microwave Drawer Manual: A Comprehensive Guide

This manual provides detailed instructions for Sharp SMD2470 series microwave drawer ovens (SMD2470AS, SMD2470AH, SMD2470ASY). It covers installation, operation, safety, and troubleshooting.

Sharp’s innovative microwave drawer ovens redefine kitchen convenience and design. Unlike traditional models, these units install seamlessly into cabinetry, offering flexible placement beneath islands, peninsulas, or standard counters. The SMD2470 series – including the SMD2470AS, SMD2470AH, and SMD2470ASY – provides a spacious 1.2 cubic foot capacity, accommodating larger dishes.

Featuring concealed controls and sensor cooking, these drawers blend functionality with a sleek aesthetic, enhancing any modern kitchen.

Understanding the SMD2470 Series (SMD2470AS, SMD2470AH, SMD2470ASY)

The Sharp SMD2470 series comprises three distinct models: the SMD2470AS (2014 stainless steel), the SMD2470AH (black stainless steel), and the SMD2470ASY. All share a 1.2 cubic foot capacity and 950W/1000W power. Key differences lie in the finish and year of manufacture. The SMD2470AH boasts a modern black stainless steel exterior, while the SMD2470AS is a classic stainless steel option.

Each model features a concealed control panel for a streamlined look.

Key Features and Benefits

Sharp’s SMD2470 series microwave drawers offer unique advantages. Flexible installation allows placement under islands, peninsulas, or cabinetry. The spacious 1.2 cubic foot capacity accommodates large dishes, like 4-quart casseroles. A concealed control panel with a digital LCD display provides a sleek, modern aesthetic.

Enjoy sensor cooking, reheat, and keep-warm functions for convenient meal preparation.

Flexible Installation Options

Sharp’s SMD2470 series microwave drawers distinguish themselves with versatile placement. Unlike traditional microwaves, these models can be installed beneath kitchen islands, peninsulas, or standard cabinetry. They also integrate seamlessly below wall ovens, offering design flexibility.

This adaptability allows for a streamlined kitchen aesthetic and maximizes counter space, enhancing both functionality and visual appeal within your home.

Spacious 1.2 Cubic Foot Capacity

The Sharp SMD2470 series microwave drawer boasts a generous 1.2 cubic foot interior. This substantial capacity comfortably accommodates a variety of dishes, including a 4-quart casserole dish or a sizable 20-ounce cup.

Its roomy design simplifies meal preparation, allowing you to heat larger portions or multiple items simultaneously, making it ideal for families and entertaining guests with ease.

Concealed Control Panel with Digital LCD Display

The Sharp SMD2470 series features a sleek, concealed control panel integrated with a clear digital LCD display. This design maintains a streamlined kitchen aesthetic while providing intuitive operation.

The Easy Touch controls offer effortless access to various cooking functions, timer settings, and power levels. The digital display clearly shows selected settings and remaining cook times for convenient monitoring.

Safety Precautions

Important safety guidelines must be followed when installing and operating your Sharp microwave drawer. Ensure proper grounding to prevent electrical shock. Avoid placing metallic objects inside, as they can cause sparks and damage the unit.

To prevent interference, keep the area around the oven clear. Never operate the oven if the door doesn’t close properly or is damaged. Always supervise children when the appliance is in use.

General Safety Guidelines

Sharp microwave drawer ovens are designed for household use only. Do not use outdoors or for commercial purposes. Regularly inspect the power cord for damage, and never operate with a damaged cord.

Avoid operating the oven empty, as this can damage the magnetron. Always use microwave-safe containers and utensils. Never attempt to repair the oven yourself; contact qualified service personnel for assistance. Keep ventilation clear during operation.

Proper Grounding Instructions

Sharp microwave drawer ovens must be properly grounded to minimize the risk of electric shock. This appliance is equipped with a three-prong grounding plug.

Do not defeat the purpose of the grounding plug by removing the grounding prong. If an extension cord is necessary, use a heavy-duty, three-wire grounded extension cord. Ensure the outlet is properly grounded. Improper grounding can result in a hazard.

Avoiding Interference

Sharp microwave drawer ovens can experience interference from other electrical devices. To minimize this, do not use the microwave near operating radio receivers or televisions.

Keep the microwave away from sources of electromagnetic radiation. Ensure proper ventilation around the appliance. Interference may cause temporary operational disruption. If persistent issues occur, try relocating the microwave or the interfering device.

Operating Instructions

Sharp’s SMD2470 series offers intuitive operation. Begin with initial setup, programming the clock and confirming correct voltage. Utilize sensor cooking functions for optimal results with various foods – the microwave automatically adjusts cooking time and power.

For customized cooking, employ manual power level settings. Always refer to recipe guidelines and start with shorter cook times, adding more as needed. Repeat touching number pads selects quantity.

Initial Setup and Programming

Upon installation, ensure the Sharp microwave drawer is properly grounded. Begin by programming the clock using the touchpad controls; confirm the correct time display. Familiarize yourself with the digital LCD display’s functions for easy navigation.

The SMD2470 series requires initial setup to optimize performance. Verify the power supply and test basic functions before first use. Refer to the full manual for detailed programming steps.

Sensor Cooking Functions

Sharp’s sensor cooking automatically adjusts cooking time and power levels based on the moisture levels detected during the cooking process. This feature ensures optimal results for various foods, eliminating guesswork. Utilize the sensor reheat function for leftovers, and the sensor cook options for potatoes, popcorn, and more.

For best results, ensure food is uncovered and properly placed within the SMD2470 series microwave drawer. Refer to the manual for specific sensor cooking guidelines.

Manual Power Level Settings

The Sharp SMD2470 series allows for precise control via manual power level settings. Users can select power levels from 10% to 100% in increments, ideal for delicate tasks like melting chocolate or simmering sauces. Access these settings through the control panel, adjusting cooking time accordingly.

Experiment with different power levels to achieve desired results, referencing recipes for recommended settings. Remember, lower power levels cook more evenly but require longer times.

Control Panel Overview

The Sharp SMD2470 series features a concealed control panel with a digital LCD display for intuitive operation. Touchpad controls manage functions like time entry, power levels, and sensor cooking. The display clearly shows cooking time, power level, and selected functions.

Dedicated buttons simplify tasks, while the timer and clock settings offer added convenience. Familiarize yourself with each control for optimal use of your microwave drawer.

Digital Display Functions

The digital LCD display on your Sharp microwave drawer provides crucial information during operation. It prominently shows the remaining cooking time, updating in real-time as the cycle progresses. The selected power level, ranging from 10% to 100%, is also clearly indicated.

Furthermore, the display communicates selected functions, such as sensor cooking modes or timer settings. Error codes, if any, will appear here to aid in troubleshooting.

Touchpad Controls Explained

The Sharp microwave drawer features intuitive touchpad controls. Number pads allow direct time entry, with repeated touches selecting quantities. “Start” initiates cooking, while “Stop/Clear” halts operation or resets settings. “Sensor Cook” activates automatic programs based on food type.

Dedicated buttons manage functions like “Reheat,” “Keep Warm,” and power level adjustments. The “Timer” button sets a countdown, independent of microwave operation. Explore each function for optimal use!

Timer and Clock Settings

Setting the clock ensures accurate timing for all functions. Press “Clock” followed by the desired time using the number pad, then press “Start” to confirm. The timer operates independently, useful for reminders or cooking durations. Press “Timer,” enter the time, and select “Start.”

To check remaining timer duration, simply press the “Timer” button. The display will show the countdown. Proper clock and timer settings enhance the Sharp microwave drawer’s usability.

Cleaning and Maintenance

Regular cleaning maintains optimal performance and extends the life of your Sharp microwave drawer. For exterior surfaces, use a damp cloth and mild detergent; Avoid abrasive cleaners that could damage the finish, especially on stainless steel models like the SMD2470AH.

Interior cleaning involves wiping down the cavity with a damp cloth after each use. For stubborn splatters, steam clean by heating a cup of water for a few minutes. Always unplug the unit before cleaning.

Exterior Cleaning Procedures

To clean the exterior of your Sharp microwave drawer (like the SMD2470ASY), use a soft, damp cloth with mild dish soap. Avoid abrasive cleaners, scouring pads, or harsh chemicals, particularly on black stainless steel models such as the SMD2470AH.

Wipe down the control panel gently. For fingerprints, a stainless steel cleaner can be used, following the product’s instructions. Ensure the unit is cool and unplugged before cleaning. Dry thoroughly with a clean cloth.

Interior Cleaning Recommendations

Regularly clean the interior of your Sharp microwave drawer (SMD2470AS, SMD2470AH, or SMD2470ASY) to prevent food buildup. Use a damp cloth with mild soap, or steam clean by heating a cup of water for several minutes.

Avoid harsh abrasives. For stubborn stains, a baking soda paste can be gently applied. Always unplug the unit before cleaning. Ensure the interior is completely dry before resuming operation, maintaining its 1.2 cubic foot capacity.

Troubleshooting Common Issues

If your Sharp microwave drawer (SMD2470AH, SMD2470ASY, SMD2470AS) isn’t heating, check the power supply and ensure the door is fully closed. For control panel malfunctions, try resetting the appliance.

Repeated touchpad issues may require professional service. Refer to the error code section for specific meanings. A 950W/1000W output should be expected; lower power may indicate a problem needing attention.

Troubleshooting

This section addresses common issues with your Sharp microwave drawer (SMD2470AS, SMD2470AH, SMD2470ASY). If the microwave isn’t heating, verify power and door closure. Control panel malfunctions may require a reset.

Consult the error code list for specific diagnostics. Remember that models like the SMD2470AH deliver 1000 Watts; reduced power signals a potential problem needing professional attention. Always prioritize safety when troubleshooting.

Microwave Not Heating

If your Sharp drawer microwave (SMD2470AS, SMD2470AH, or SMD2470ASY) isn’t heating, first ensure it’s properly plugged in and receiving power. Verify the door is securely closed, as a safety interlock prevents operation when open.

Check for any obstructions inside. If the issue persists, a faulty magnetron or high-voltage diode could be the cause, requiring professional repair. Do not attempt self-repair of these components.

Control Panel Malfunctions

If the Sharp microwave drawer’s (SMD2470AH, SMD2470ASY, SMD2470AS) control panel isn’t responding, try resetting the appliance by unplugging it for several minutes, then plugging it back in. Repeatedly touching the same number pad can sometimes cause issues; avoid this.

If problems continue, a faulty touchpad or internal electronic component may require professional service. Do not attempt to disassemble or repair the control panel yourself.

Error Codes and Their Meanings

While specific error codes for Sharp SMD2470 series microwave drawers (SMD2470AS, SMD2470AH, SMD2470ASY) aren’t extensively detailed in readily available resources, a general malfunction often displays as a flashing error or a lack of response.

If an error appears, unplug the unit for a few minutes, then restart. If the issue persists, consult a qualified technician for diagnosis and repair, referencing the model number for accurate support.

Warranty Information

Sharp provides a limited warranty for the SMD2470 series microwave drawer ovens (SMD2470AS, SMD2470AH, SMD2470ASY) against manufacturing defects. This warranty typically covers parts and labor for a specified period from the date of purchase.

However, it doesn’t cover incidental or consequential damages, and varies by state. Specific details, exclusions, and claim procedures are outlined in the warranty documentation included with your appliance.

Coverage Details

Sharp’s warranty for the SMD2470 series covers defects in materials and workmanship under normal household use. This includes component failures, but excludes damage from misuse, accident, or unauthorized repair.

Warranty length differs, but generally provides one year of parts and labor coverage. Proof of purchase is required for all claims. The warranty is valid only for the original purchaser and applies to home use microwave drawer ovens.

Exclusions and Limitations

This warranty doesn’t cover incidental or consequential damages. Some states don’t allow these exclusions, so they may not apply to you. Damage from improper installation, power surges, or commercial use voids the warranty.

Unauthorized repairs or modifications also invalidate coverage. The warranty is specifically for SMD2470AS, SMD2470AH, and SMD2470ASY models used as intended, and doesn’t cover cosmetic issues.

State-Specific Legal Rights

Warranty provisions vary by state. Some states offer additional rights beyond those outlined here, including the right to have repairs completed within a reasonable timeframe. Other states may have differing limitations on implied warranties.

This warranty gives specific legal rights, and you may possess others depending on your location. Consult your state’s consumer protection laws for complete details regarding your rights and remedies.

Technical Specifications

Dimensions and Weight: The Sharp SMD2470ASY measures 24 inches wide, offering flexible installation. Specific weight details vary slightly by model but generally fall within a standard range for built-in drawer microwaves.

Power Consumption: These models operate at 950W/1000W, providing efficient heating. The 1.2 cubic foot capacity accommodates various dish sizes. Detailed electrical requirements are listed in the installation guide.

Dimensions and Weight

The Sharp SMD2470 series boasts a 24-inch width, designed for seamless integration beneath kitchen islands, peninsulas, or cabinetry. While precise dimensions vary slightly between models – SMD2470AS, SMD2470AH, and SMD2470ASY – they maintain a consistent profile.

Weight is a crucial factor for installation; expect a substantial unit due to its construction. Refer to the full installation guide for exact weight specifications to ensure proper support.

Power Consumption

Sharp SMD2470 series microwave drawer ovens operate on standard household electrical current. Models, including the SMD2470AH and SMD2470ASY, typically require a dedicated 120V, 60Hz circuit. Power consumption varies based on wattage and usage.

Expect a range, with typical operation drawing between 950W to 1000W. Standby power consumption is minimal. Always consult the detailed specifications label on your specific model for accurate power requirements.

Wattage (950W/1000W)

Sharp SMD2470 series microwave drawer ovens offer cooking power at either 950 watts or 1000 watts, depending on the specific model. The SMD2470AH, for example, features 1000W, while others utilize 950W. This wattage impacts cooking speed and efficiency.

Higher wattage generally means faster cooking times. Ensure your electrical circuit can handle the chosen model’s power demand for optimal and safe operation. Refer to your model’s label for precise wattage information.

Model Variations and Updates

Sharp offers several variations within the SMD2470 series. The SMD2470AS is identified as a 2014 model with a stainless steel finish. The SMD2470AH features a modern black stainless steel exterior. Lastly, the SMD2470ASY provides another stylish option.

These models share core functionality but differ in aesthetics and potentially minor feature updates. Always refer to the specific manual for your purchased model to ensure accurate operation and understanding of its unique characteristics.

SMD2470AS (2014 Model)

The SMD2470AS, released in 2014, is a stainless steel Sharp microwave drawer offering 1.2 cubic feet of capacity and 950 watts of power. It features a concealed control panel with a digital LCD display for easy operation.

This model prioritizes flexible installation, fitting under islands or cabinetry. It’s designed for home use and provides sensor cooking functions for optimal results. Refer to the complete manual for detailed instructions and safety precautions specific to this earlier version.

SMD2470AH (Black Stainless Steel)

The SMD2470AH Sharp microwave drawer boasts a sleek black stainless steel finish, offering a modern aesthetic for your kitchen. It maintains the 1.2 cubic foot capacity and delivers 950 watts of cooking power.

Featuring an easy-touch, hidden control panel with a digital LCD, operation is intuitive. This model offers design flexibility, timer functions, and convenient reheat/keep warm settings. Consult the full manual for detailed guidance on installation and safe usage.

SMD2470ASY

The SMD2470ASY is a 24-inch Sharp Microwave Drawer Oven designed for flexible placement – under islands, peninsulas, or cabinetry. It features a spacious 1.2 cubic foot interior, accommodating larger dishes like 4-quart casseroles.

This model offers a concealed control panel with a digital LCD display for easy operation. It delivers powerful cooking with its 950-watt output. Refer to the complete manual for detailed instructions on setup, sensor cooking, and maintenance procedures.
